瑞徽电子可以依据最新的国际国内标准提供光伏相关产品的全套测试方案。

光伏零配件测试方案
Test Phase Designation Test Equipment / Model
UL1703, 19 Temperature Test EP series DC power
    Recorder
    High Temperature Oven / DDO-0198H
UL1703, 21 Leakage Current Test High resistance tester
UL1703, 22 Strain Relief Test Servo Control System Universal Testing Machine / FTA-10K
UL1703, 26 Dielectric Voltage-Withstand Test Electrical safety compliance analyzer
UL1703, 27 Wet Insulation-Resistance Test High resistance tester
UL1703, 28 Reverse Current Overload Test EP series DC power
UL1703, 30 Impact Test/Low Temperature Impact Test Impact tester / UJM2069
UL1703, 33 Water Spray Test UL RAIN SPRAY TEST APPARATUS / RTA-01
UL1703, 34 Accelerated Aging Test High Temperature Oven / DDO-0198H

UL 486A-486B, 9.3 Static Heating Sequence
9.3.1 Static heating test  60 Hz test current / (12AWG/35A;10AWG/50A)
9.3.2 Secureness test  Secureness tester :UCM-2068
9.3.3 Repeated Static heating test
9.3.4  Pull out test Servo Control System Universal Testing Machine / FTA-10K

EN50548:5.3.8 Mechanical strength at lower temperatures Spring Hammer / TCJM-1071
EN50548:5.3.12.1 Flammability test or approval of manufacturer of material Vertical Flame Tester / RE-4001-UL94
EN50548:5.3.14  Glow wire test Glow Wire Tester / RE-4002
EN50548:5.3.13 Ball pressure test Ball pressure tester / TJM-1068;
    High Temperature Oven / DDO-0198H
EN50548:A3 Polarisation IEC61032 test probe 11/TP-11; Electrical Contact Indicator/TPS-01
EN50548:5.14 Cable Anchorage Cable Anchorage Tester / TCJM-1071
EN50548:5.3.18 Bypass diode thermal test Bypass diode thermal test system
EN50521:B1 Contact resistance NanoVolt/Micro-Ohm Meter
EN50521:6.3.6 bending test Bending Tester/TCM-1072;EP series DC power
EN50521:6.3.8 a) Impulse withstand voltage Impulse voltage tester
EN50521:6.3.3.2 IP code  1.DUST TEST CHAMBER / DCT-100
    2.IP CODE JET NOZZLES / JET-03
